Custom Iron Gate Installation & Fabrication in DFW
Iron Gates Built Specifically for Your Unique Property Entry
We custom weld your gate from raw steel rather than modifying prefabricated catalog panels.
Custom iron gate fabrication means we build your gate directly from raw structural steel. It is never a catalog frame modified awkwardly at the job site. It starts as heavy steel bar and tube stock. It ends as a finished gate sized to your exact driveway width.
Star Gate & Fence fabricates iron gates exclusively in-house. Our direct employees perform the intricate welding, grinding, and finishing at our local facility. We absolutely never use outside subcontractors for fabrication or installation. When your gate arrives at your property, it fits perfectly.
Standard catalog panels come in fixed widths, typically increments of two feet. If your driveway does not divide cleanly, standard panels leave large, visible gaps. Custom fabrication eliminates those structural problems entirely before they ever start.
DFW Neighborhoods That Demand Custom Gate Measurements
Curved driveways and custom masonry columns require gates built to precise architectural specifications.
Luxury neighborhoods across DFW share a common trait regarding property entrances. Entries in Highland Park, Preston Hollow, and Southlake rarely conform to standard catalog dimensions. A curved driveway approach drastically changes the required hinge geometry. An architectural facade designed around a specific arch profile demands a matching gate.
Upscale residential corridors in Dallas were built before prefabricated gate panels dominated the market. These grand entries were intentionally designed, and the gates should match. This same dynamic applies to commercial properties in Las Colinas and Uptown. A stock gate installed into a custom facade looks out of place.
We fabricate gates to complement your existing architecture. We select the specific arch profile and picket spacing to match your property perfectly.
Why We Measure Everything Before Fabrication Begins
We measure your columns at multiple heights because older masonry shifts significantly over time.
Every successful fabrication job starts with exact measurements. Founder Elia Amiel recently measured a replacement gate in Lakewood. The original standard panel was hung between two large stone columns. Over twelve years, the panel developed a severe bind at the latch. It refused to close cleanly.
We measured the masonry opening at the top, middle, and bottom. The columns were eleven inches wider at the base than at the top. Heavy stone inevitably shifts over time in older Dallas neighborhoods. A standard rectangular panel will always bind mechanically in that shifted opening.
We fabricated a new panel with a slight taper built into the vertical frame. The top matched the top opening, and the bottom matched the wider base. The gate now travels in a perfectly true line. A standard catalog panel simply cannot accommodate those unique structural realities.
Protecting Your Iron Gate Against Extreme DFW Weather
We utilize premium powder coating to prevent intense North Texas sun from destroying your finish.
The DFW Metroplex averages more than 230 days of intense direct sun per year. Summer temperatures easily hold above 95 degrees for consecutive weeks. A liquid paint finish that survives milder climates will quickly chalk and peel here. Sustained UV load destroys cheap, film-based finishes on outdoor metal.
We combat this by utilizing advanced powder coating. Electrostatically charged pigment particles are applied directly to the bare metal. The gate is then cured inside a high-heat oven. The finish bonds molecularly to the metal surface rather than sitting on top.
Powder coating heavily resists UV chalking and edge chipping. It holds vibrant color far longer under the brutal Texas sun. We apply this durable powder coating before the gate ever leaves our shop.
Our Strict Engineering Standards for Custom Iron Work
We build heavy gates that meet strict structural engineering and international safety codes.
Every gate we fabricate meets elite standards for structural integrity and physical safety.
Structural Steel Selection: We fabricate gates from heavy structural steel tube and bar stock. Wider panels utilize heavier-wall tubes in the main frame to completely resist flexing.
Premium Weld Quality: Our direct employees fully weld every frame joint and decorative element. We guarantee maximum structural integrity without ever relying on weak mechanical fasteners.
Safety Compliance: We adhere strictly to ASTM F2200 physical safety geometry standards. We space the pickets correctly to eliminate dangerous reach-through pinch points.
Deep Concrete Footings: Gate posts are set using the strict one-third depth rule. The massive concrete volume safely resists the extreme lateral force of heavy iron panels.
Regional Visibility Rules: We verify your custom gate meets local municipal intersection visibility triangles. This preserves driver line-of-sight and keeps your property legally compliant.
How We Execute a Custom Iron Gate Build
We control the entire fabrication and installation process to guarantee a perfect outcome.
Site Measurement and Custom Design
We visit your property to confirm exact dimensions and driveway slope conditions.
We measure the entry opening at multiple points because masonry columns settle unevenly. We confirm the ideal arch profile, picket style, and specific swing direction. We sketch the custom profile at your property before finalizing the design.
Custom Steel Fabrication
Our direct employees cut, weld, and assemble your gate at our local shop.
The frame is completely squared and fully welded at every single joint. We weld decorative scrolls and arch curves meticulously before final grinding. We then apply the heat-cured powder coating for maximum exterior durability.
Installation and Automation Testing
We set heavy posts in deep concrete before mounting the automated gate hardware.
We test the physical swing through its full arc to confirm perfect latch engagement. We then mount the automatic operator and program the active limit switches. We test the photoelectric safety sensors completely before handing the project over.
Serving the Entire DFW Metroplex
We fabricate and install premium iron gates across all major North Texas counties.
Star Gate & Fence operates without geographic restrictions across the DFW Metroplex. We serve residential properties in University Park, Lakewood, Frisco, and Southlake. We also handle commercial installations in Uptown Dallas, the Design District, and Las Colinas.
Ready to Build a Custom Gate for Your Entry?
Schedule a precise measurement appointment to start your custom iron gate project.
Contact Star Gate & Fence to schedule your on-site design and measurement visit. Call 469-778-0871 or email info@stargateandfence.com to reach our team. Bring your design ideas, and we will handle the exact structural engineering.
Frequently Asked Questions About Custom Iron Gates
Find quick answers regarding our fabrication process and custom iron gate installations.
Do you hire subcontractors to weld your gates?
No, every gate is fabricated exclusively by direct Star Gate & Fence employees.
We never use outside subcontractors for welding or field installation. Our in-house team handles everything from raw steel cutting to final concrete post setting.
What finish do you use on your iron gates?
We utilize heat-cured powder coating for superior durability against the Texas sun.
Powder coating bonds molecularly to the metal, making it far more durable than paint. It heavily resists UV fading, chalking, and edge chipping.
Are your heavy iron gates legally safe?
Yes, we follow strict ASTM F2200 standards for physical gate construction.
We properly space the iron pickets to prevent dangerous reach-through entrapment hazards. We also ensure correct bottom clearance to prevent dragging.
How deep do you set the iron gate posts?
We strictly follow the one-third depth rule for all gate post footings.
This deep concrete footing combats the highly expansive North Texas clay soil. It prevents heavy iron gates from sagging and binding over time.
